XtremeEPP ™ 1890 TEG Toughened Epoxy Grade Foam

Compliance Info

Slide 1 of 4, currently active
Slide 2 of 4
Slide 3 of 4
Slide 4 of 4

General Info

XtremeEPP ™ 1890 TEG is a toughened epoxy resin matrix composite with high strength and stiffness. The hollow glass spheres lower the density by roughly 40% as compared to standard epoxy systems. The lower density also results in a lower thermal conductivity thereby increasing its effectiveness as an insulator, better dimensional stability over a range of temperatures, and lower dielectic resistivity for electrical insulation applications

Key Properties

Lower Density for Weight Reduction & Buoyancy
Enhanced Dimensional Stability Lower CLTE
Lower Thermal Conductivity
High Operating Temp 350F/176C

Limitations

Not Intended For Bearing Applications

Applications

Structural Components
Thermal Insulating Components
Weight Reduction Metal Replacement Structural Applications

Resin Trade Names

Manufacturer Trade Names

XtremeEPP ™ 1890 TEG

Boedeker Plastics, Inc. stocks & supplies plastic sheet, rod, tube, film and custom profiles and machine parts from these shapes that are produced from plastic resin. In many cases the manufacturer of the shape has their own product trade name. If your specification calls for a specific resin grade or manufacturer trade name, we can supply a shape made from that resin to meet your specification or suggest an equal. If you require a specific resin or brand it must be specified at the time of order.

Available Sizes

Available in Sheet and Rod: Sheet Thickness 1.000 in to 6.000 in Sheet Size 24.000 in x 26.000 in Rod Diameters 2.000 in to 6.000 Rod Length 24.000 in lengths

Available Colors

Safety Data Sheet

Typical Properties of XtremeEPP ™ 1890 TEG Toughened Epoxy Grade Foam

DETAIL
Description			Value
Material Type			Thermoset Foam
Trade Name			XtremeEPP ™ 1890 TEG
Additives			Proprietary
Color			Red
PHYSICAL
Property	Test	Unit of Measure	Value
Density	ASTM D2240	g/cm³	0.72
	ASTM D2240	lb/in³	0.026
Water Absorption, 24 hrs, Immersion	ASTM D570	% by wt.	0.1
MECHANICAL
Property	Test	Unit of Measure	Value
Tensile Strength	ASTM D628	psi	6,360
Tensile Modulus	ASTM D628	psi	497,000
Tensile Elongation at Break	ASTM D638	%	<2
Flexural Strength	ASTM D695	psi	8,780
Flexural Modulus	ASTM D695	psi	510,000
Compressive Strength	ASTM D695	psi max	14,980
Compressive Modulus	ASTM D695	psi	475,000
Hardness	ASTM D2240	Shore D	75 Shore D
THERMAL
Property	Test	Unit of Measure	Value
Coefficient of Linear Thermal Expansion	ASTM E228	x 10-5 in./in./°F	2.2
Max Continuous Operating Temp		°C	176
		°F	350
Thermal Conductivity	ASTM E1225	BTU-in/ft²-hr-°F	0.1
ELECTRICAL
Property	Test	Unit of Measure	Value
Dielectric Constant at 1 MHz	ASTM D150	1 MHz	2.1
COMPLIANCE
Description			Value
FDA			No
USDA			No
NSF			No
3-A Dairy			No
Canadian Food Inspection Agency			No
USP Class VI			No
OTHER
Description			Value
UV Resistant			No
Relative Cost			$$$$
Machinability			3

Relative cost based on a scale of one dollar sign ($) as the lowesACt to ten dollar signs ($$$$$$$$$$) as the highest. Machinability based on a scale of 1 to 10, with 1 being the easiest and 10 being the most difficult to machine. NOTE: All information contained on www.boedeker.com, downloadable documents and printed literature is intended for technical reference only and considered to be accurate for reference purposes only. Boedeker Plastics, Inc. makes no guarantee and offers no warranty for fitness in use and strongly recommends the user validate any plastic, machined part, or product in a specific application for fitness in use.

XtremeEPP™ is a registered trademark of Boedeker Plastics, Inc.
