Fluorosint ® 207

Compare Go To Comparison Add Additional Products For Comparison

-

1. Select Shape

2. Please Select Thickness

2. Please Select Diameter

2. Please Select Outer Diameter

2. Please Select Type & Size

Unit of Measure

In order to provide an accurate quote for your part, you'll need to provide some information through our custom quote request form.

3. Please Select Dimensions *

Sheet widths and lengths are cut to nominal dimensions; Rod lengths are also cut to nominal dimensions. Nominal cuts can be undersized by up to .200 inches. Cut-to-size items are non-refundable. See our return policy for more details. Contact us if you need precision cut sizes.

3. Please Select Length *

Sheet widths and lengths are cut to nominal dimensions; Rod lengths are also cut to nominal dimensions. Nominal cuts can be undersized by up to .200 inches. Cut-to-size items are non-refundable. See our return policy for more details. Contact us if you need precision cut sizes.

Unit Price

Subtotal

Note: There is a $50.00 line item minimum on all orders.

General Info

Fluorosint® 207 PTFE’s unmatched dimensional stability, excellent creep resistance and white color uniquely position this material to serve FDA regulated applications. It is non-permeable in steam and complies with the FDA’s regulation 21 CFR 175.300. Its relative wear rate is 1/20 the rate of PTFE below 300°F (150°C) making it an excellent choice for aggressive service bearings and bushings. Ideal for lower pressure seats and seals where virgin PTFE fails and food contact compliance may be required.

Learn more about the complete line of Fluorosint® Products


Key Properties

  • FDA Compliant
  • Very good wear resistance
  • Very low coef/cient of friction

Limitations

  • Lower Mechanical Properties than other high performance materials

Applications

  • Appliance Wear Parts & Seals
  • Bushings & Bearings
  • Mixer Paddles & Components
  • Pumps Seals for Food Contact Applications
  • Seals
  • Valve Seats for Food Contact Applications

Resin Trade Names

Manufacturer Trade Names

  • Fluorosint® 207

Boedeker Plastics, Inc. stocks & supplies plastic sheet, rod, tube, film and custom profiles and machine parts from these shapes that are produced from plastic resin. In many cases the manufacturer of the shape has their own product trade name. If your specification calls for a specific resin grade or manufacturer trade name, we can supply a shape made from that resin to meet your specification or suggest an equal. If you require a specific resin or brand it must be specified at the time of order.

Available Sizes

Available Colors

  • White

Safety Data Sheet

Download Safety Data Sheet

Typical Properties of Fluorosint ® 207

DETAIL
Description Value
Material Type Semi-Crystalline Thermoplastic Fluoropolymer
Chemical Name PTFE Polytetrafluoroethylene
Trade Name Fluorosint® 207
Additives FDA Compliant Mica
Color White
Manufacturer Quadrant
PHYSICAL
Property Test Unit of Measure Value
Density ASTM D792 g/cm³ 2.3
  ASTM D792 lb/in³ 0.083
Water Absorption, 24 hrs, Immersion ASTM D570 % by wt. 0.03
Water Absorption, Saturation, Immersion ASTM D570 % by wt. 0.2
MECHANICAL
Property Test Unit of Measure Value
Tensile Strength ASTM D638 psi 1,500
Tensile Modulus ASTM D638 psi 250,000
Tensile Elongation at Break ASTM D638 % 50
Flexural Strength ASTM D790 psi 2,000
Flexural Modulus ASTM D790 psi 350,000
Compressive Strength ASTM D695 psi 3,800
Compressive Modulus ASTM D695 psi 225,000
Hardness ASTM D785 NA Rockwell R50
IZOD Impact-Notched ASTM D256 ft-lb/in 1
Dynamic Coefficient of Friction QTM 55007 (Dry vs Steel) NA 0.1
Wear K Factor QTM 55010 in³-min/ft-lbs-hr 85
Limiting PV QTM 55007 psi-fpm 8,000
THERMAL
Property Test Unit of Measure Value
Coefficient of Linear Thermal Expansion ASTM D696 x 10-5 in./in./°F 5.7
Heat Deflection Temp ASTM D648 °C at 264 psi 99
  ASTM D648 °F at 264 psi 210
Melting Point Temp ASTM D3418 °C 327
  ASTM D3418 °F 621
Max Continuous Operating Temp °C 260
  °F 500
Minimum Operating Temp °C -200
  °F -328
Thermal Conductivity ASTM C117 BTU-in/ft²-hr-°F 3.05
Flammability Rating UL94 NA V-0
ELECTRICAL
Property Test Unit of Measure Value
Dielectric Strength ASTM D149 V/mil 200
Dielectric Constant at 1 MHz ASTM D150 NA 2.65
Dissipation Factor at 1 MHz ASTM D150 NA 0.008
Surface Resistivity ASTM D257 ohm/square >10^13
COMPLIANCE
Description Value
FDA Yes
USDA Yes
NSF No
3-A Dairy No
Canadian Food Inspection Agency No
USP Class VI No
OTHER
Description Value
UV Resistant Yes
Relative Cost $$$$$
Machinability 1

Relative cost based on a scale of one dollar sign ($) as the lowest to ten dollar signs ($$$$$$$$$$) as the highest. Machinability based on a scale of 1 to 10, with 1 being the easiest and 10 being the most difficult to machine. NOTE: All information contained on www.boedeker.com, downloadable documents and printed literature is intended for technical reference only and considered to be accurate for reference purposes only. Boedeker Plastics, Inc. makes no guarantee and offers no warranty for fitness in use and strongly recommends the user validate any plastic, machined part, or product in a specific application for fitness in use.

Fluorosint® is a registered trademark of Quadrant Engineering Plastic Products.
