XtremeEPP ™ 1889 ETP Engineered Thermoplastic Grade Foam

Compare Go To Comparison Add Additional Products For Comparison

-

1. Select Shape

2. Please Select Thickness

2. Please Select Diameter

2. Please Select Outer Diameter

2. Please Select Type & Size

Unit of Measure

In order to provide an accurate quote for your part, you'll need to provide some information through our custom quote request form.

3. Please Select Dimensions *

Sheet widths and lengths are cut to nominal dimensions; Rod lengths are also cut to nominal dimensions. Nominal cuts can be undersized by up to .200 inches. Cut-to-size items are non-refundable. See our return policy for more details. Contact us if you need precision cut sizes.

3. Please Select Length *

Sheet widths and lengths are cut to nominal dimensions; Rod lengths are also cut to nominal dimensions. Nominal cuts can be undersized by up to .200 inches. Cut-to-size items are non-refundable. See our return policy for more details. Contact us if you need precision cut sizes.

General Info

XtremeEPP ™ 1889 ETP is an Engineered Thermoplastic Foam, this material is unique in many ways.   This material offers weight savings of greater than 45% when compared to polymers like Delrin® or PVC with better dimensional stability.  The low density also means lower thermal conductivity, specific heat and dielectric constant than solid polymers.  These improved properties translate to better electrical and thermal insulation and higher dimensional stability at elevated temperatures.

Key Properties

  • Low Thermal Conductivity
  • Light Weight
  • Electrical Insulator
  • Good Structural Properties
  • Excellent Dimensional Stability

Limitations

  • Not Intended For Bearing Applications

Applications

  • Structural Components
  • Thermal Insulating Components
  • Weight Reduction Metal Replacement Structural Applications

Resin Trade Names

Manufacturer Trade Names

Boedeker Plastics, Inc. stocks & supplies plastic sheet, rod, tube, film and custom profiles and machine parts from these shapes that are produced from plastic resin. In many cases the manufacturer of the shape has their own product trade name. If your specification calls for a specific resin grade or manufacturer trade name, we can supply a shape made from that resin to meet your specification or suggest an equal. If you require a specific resin or brand it must be specified at the time of order.

Available Sizes

XtremeEPP 1889 ETP is available in sheet and rod. Sheet Sizes W x L = 24 inch x 24 inch Thicknesses (inches) 1, 1.5, 2, 2.5, 3, 3.5, 4 inches Rod Sizes Length = 24 inch Diameters (inches) 3, 3.5, 4, 4.5, 5, 6, 8, 9

Available Colors

  • White

Safety Data Sheet

Contact Us

Typical Properties of XtremeEPP ™ 1889 ETP Engineered Thermoplastic Grade Foam

DETAIL
Description Value
Material Type Thermoplastic Foam
Trade Name XtremeEPP ™ 1889 ETP
Additives Proprietary
Color White
PHYSICAL
Property Test Unit of Measure Value
Density ASTM D2240 g/cm³ 0.71
  ASTM D2240 lb/in³ 0.025
Water Absorption, 24 hrs, Immersion ASTM D570 % by wt. 0.2
MECHANICAL
Property Test Unit of Measure Value
Tensile Strength ASTM D628 psi 6,250
Tensile Modulus ASTM D628 psi 350,000
Tensile Elongation at Break ASTM D638 % 7
Flexural Strength ASTM D695 psi 7,500
Flexural Modulus ASTM D695 psi 325,000
Compressive Strength ASTM D695 psi max 7,100
Compressive Modulus ASTM D695 psi 250,000
Hardness ASTM D2240 Shore D 74 Shore D
THERMAL
Property Test Unit of Measure Value
Coefficient of Linear Thermal Expansion ASTM E228 x 10-5 in./in./°F 3.76
Heat Deflection Temp ASTM D648 °C at 264 psi 176
  ASTM D648 °F at 264 psi 350
Max Continuous Operating Temp °C 176
  °F 350
Thermal Conductivity ASTM D5930 BTU-in/ft²-hr-°F 1.32
  ASTM D5930 x 10^4 cal/cm-sec-°C 4.5
ELECTRICAL
Property Test Unit of Measure Value
Dielectric Constant at 1 MHz ASTM D150 1 MHz 2.1
Surface Resistivity ASTM D257 ohm/square >10^12
COMPLIANCE
Description Value
FDA No
USDA No
NSF No
3-A Dairy No
Canadian Food Inspection Agency No
USP Class VI No
OTHER
Description Value
UV Resistant No
Relative Cost $$$
Machinability 3

Relative cost based on a scale of one dollar sign ($) as the lowest to ten dollar signs ($$$$$$$$$$) as the highest. Machinability based on a scale of 1 to 10, with 1 being the easiest and 10 being the most difficult to machine. NOTE: All information contained on www.boedeker.com, downloadable documents and printed literature is intended for technical reference only and considered to be accurate for reference purposes only. Boedeker Plastics, Inc. makes no guarantee and offers no warranty for fitness in use and strongly recommends the user validate any plastic, machined part, or product in a specific application for fitness in use.

XtremeEPP™ is a registered trademark of Boedeker Plastics, Inc.
