SIMONA ® PVC Type I

Compare Go To Comparison Add Additional Products For Comparison

-

1. Select Shape

2. Please Select Thickness

2. Please Select Diameter

2. Please Select Outer Diameter

2. Please Select Type & Size

Unit of Measure

In order to provide an accurate quote for your part, you'll need to provide some information through our custom quote request form.

3. Please Select Dimensions *

Sheet widths and lengths are cut to nominal dimensions; Rod lengths are also cut to nominal dimensions. Nominal cuts can be undersized by up to .200 inches. Cut-to-size items are non-refundable. See our return policy for more details. Contact us if you need precision cut sizes.

3. Please Select Length *

Sheet widths and lengths are cut to nominal dimensions; Rod lengths are also cut to nominal dimensions. Nominal cuts can be undersized by up to .200 inches. Cut-to-size items are non-refundable. See our return policy for more details. Contact us if you need precision cut sizes.

General Info

SIMONA® PVC Type I offers excellent chemical and corrosion resistance and is easy to fabricate, weld or machine.

Click for more information on the complete line of PVC & CPVC Plastics

Key Properties

  • Chemical & Corrosion Resistance
  • Easy to Fabricate, Weld & Machine
  • UL 94 V-0 Rated

Limitations

  • Higher Weight than many other Thermoplastics
  • Limited Operating Temperature of 140 F

Applications

  • Air-Conditioning and Ventilation Systems
  • Chemical Process Industry
  • Chemical Tank and Equipment Construction
  • Environmental Technology
  • Laboratory Equipment
  • Lining and Composite Construction
  • Mobility
  • Tanks and Equipment

Resin Trade Names

Manufacturer Trade Names

  • SIMONA® PVC Type I

Boedeker Plastics, Inc. stocks & supplies plastic sheet, rod, tube, film and custom profiles and machine parts from these shapes that are produced from plastic resin. In many cases the manufacturer of the shape has their own product trade name. If your specification calls for a specific resin grade or manufacturer trade name, we can supply a shape made from that resin to meet your specification or suggest an equal. If you require a specific resin or brand it must be specified at the time of order.

Available Sizes

Sheet Gray | Thickness .062” to 1.500” White | Thickness .125” to 1.000” Width & Length 48.000” x 96.000” Gray | Thickness 1.500” to 2.000” Welding Rod Gray | Diameters .118”, .157” & .197” Rod Gray | Diameters .375” to 2.000” 120.000” Lengths Natural | Diameters 2.250” to 8.000” 60.000” Lengths Boedeker offers cut to size service on all in-stock items and same day shipping. If you don’t see the size your looking for contact us for alternative options.

Available Colors

  • Gray
  • White
  • Black

Safety Data Sheet

Download Safety Data Sheet

Typical Properties of SIMONA ® PVC Type I

DETAIL
Description Value
Material Type Amorphous Thermoplastic
Chemical Name PVC Polyvinyl Chloride
Trade Name SIMONA® PVC Type I
Additives Unfilled
Color Gray
Manufacturer SIMONA
PHYSICAL
Property Test Unit of Measure Value
Density ASTM D792 g/cm³ 1.41
  ASTM D792 lb/in³ 0.051
MECHANICAL
Property Test Unit of Measure Value
Tensile Strength ASTM D638 psi 9,000
Tensile Modulus ASTM D638 psi 486,000
Hardness ASTM D2240 NA Shore D84
IZOD Impact-Notched ASTM D256 ft-lb/in 0.8
THERMAL
Property Test Unit of Measure Value
Coefficient of Linear Thermal Expansion ASTM D696 x 10-5 in./in./°F 4.4
Max Continuous Operating Temp °C 60
  °F 140
Minimum Operating Temp °C -10
  °F 14
Flammability Rating UL94 NA V-0
COMPLIANCE
Description Value
FDA No
USDA No
NSF No
3-A Dairy No
Canadian Food Inspection Agency No
USP Class VI No
OTHER
Description Value
Relative Cost $
Machinability 2

Relative cost based on a scale of one dollar sign ($) as the lowest to ten dollar signs ($$$$$$$$$$) as the highest. Machinability based on a scale of 1 to 10, with 1 being the easiest and 10 being the most difficult to machine. NOTE: All information contained on www.boedeker.com, downloadable documents and printed literature is intended for technical reference only and considered to be accurate for reference purposes only. Boedeker Plastics, Inc. makes no guarantee and offers no warranty for fitness in use and strongly recommends the user validate any plastic, machined part, or product in a specific application for fitness in use.

SIMONA® is a registered trademark of Simona.
