Techtron ® HPV PPS

Compare Go To Comparison Add Additional Products For Comparison

-

1. Select Shape

2. Please Select Thickness

2. Please Select Diameter

2. Please Select Outer Diameter

2. Please Select Type & Size

Unit of Measure

In order to provide an accurate quote for your part, you'll need to provide some information through our custom quote request form.

3. Please Select Dimensions *

Sheet widths and lengths are cut to nominal dimensions; Rod lengths are also cut to nominal dimensions. Nominal cuts can be undersized by up to .200 inches. Cut-to-size items are non-refundable. See our return policy for more details. Contact us if you need precision cut sizes.

3. Please Select Length *

Sheet widths and lengths are cut to nominal dimensions; Rod lengths are also cut to nominal dimensions. Nominal cuts can be undersized by up to .200 inches. Cut-to-size items are non-refundable. See our return policy for more details. Contact us if you need precision cut sizes.

Unit Price

Subtotal

Note: There is a $50.00 line item minimum on all orders.

General Info

Techtron® HPV exhibits excellent wear resistance and a low coefficient of friction. It overcomes the disadvantages of virgin PPS caused by a high coefficient of friction, and of glass fiber reinforced PPS which can cause premature wear of the counter face in moving-part applications.

Click for more information on the complete line of Techtron PPS Plastics

Click for more information on the complete line of PPS Plastics

IMPORTANT NOTE: Techtron HPV is not FDA compliant above 160F and not recommended for food processing applications over 160F

Key Properties

  • Excellent wear and frictional behavior
  • Excellent chemical and hydrolysis resistance
  • Very good dimensional stability
  • Good electrical insulating and dielectric properties
  • Inherent low flammability
  • Excellent resistance against high energy radiation
  • NSF Compliant Standards 51 & 61

Limitations

  • Low Heat Deflection Temperature
  • Moderate Impact Strength
  • Techtron HPV is not FDA compliant above 160F and not recommended for food processing applications over 160F

Applications

  • Aerospace Wear Components
  • Bushings & Bearings
  • Food Processing CIP (Clean in Place) Wash-down Components
  • Food Processing Components
  • Metal Replacement
  • Oil & Gas Components
  • Pump, Valve & Compressor Components
  • Rollers

Resin Trade Names

Manufacturer Trade Names

  • Techtron® HPV

Boedeker Plastics, Inc. stocks & supplies plastic sheet, rod, tube, film and custom profiles and machine parts from these shapes that are produced from plastic resin. In many cases the manufacturer of the shape has their own product trade name. If your specification calls for a specific resin grade or manufacturer trade name, we can supply a shape made from that resin to meet your specification or suggest an equal. If you require a specific resin or brand it must be specified at the time of order.

Available Sizes

Available Colors

  • Blue

Safety Data Sheet

Download Safety Data Sheet

Typical Properties of Techtron ® HPV PPS

DETAIL
Description Value
Material Type Semi-Crystalline Thermoplastic
Chemical Name PPS PolyPhenylene Sulfide
Trade Name Techtron® HPV
Additives Premium, Solid Lubricant
Color Blue
Manufacturer Quadrant
PHYSICAL
Property Test Unit of Measure Value
Density ASTM D792 g/cm³ 1.43
  ASTM D792 lb/in³ 0.052
Water Absorption, 24 hrs, Immersion ASTM D570 % by wt. 0.01
Water Absorption, Saturation, Immersion ASTM D570 % by wt. 0.09
MECHANICAL
Property Test Unit of Measure Value
Tensile Strength ASTM D638 psi 10,900
Tensile Modulus ASTM D638 psi 540,000
Tensile Elongation at Break ASTM D638 % 4
Flexural Strength ASTM D790 psi 10,500
Flexural Modulus ASTM D790 psi 535,000
Compressive Strength ASTM D695 psi 15,500
Compressive Modulus ASTM D695 psi 342,000
Hardness ASTM D785 NA Rockwell M84
IZOD Impact-Notched ASTM D256 ft-lb/in 1.4
Dynamic Coefficient of Friction QTM 55007 (Dry vs Steel) NA 0.2
Wear K Factor QTM 55010 in³-min/ft-lbs-hr 62
Limiting PV QTM 55007 psi-fpm 8,750
THERMAL
Property Test Unit of Measure Value
Coefficient of Linear Thermal Expansion ASTM D696 x 10-5 in./in./°F 3.3
Heat Deflection Temp ASTM D648 °C at 264 psi 116
  ASTM D648 °F at 264 psi 240
Melting Point Temp ASTM D3418 °C 280
  ASTM D3418 °F 536
Max Continuous Operating Temp °C 221
  °F 430
Minimum Operating Temp °C -20
  °F -4
Thermal Conductivity ASTM C117 BTU-in/ft²-hr-°F 2.1
Flammability Rating UL94 NA V-0
ELECTRICAL
Property Test Unit of Measure Value
Dielectric Strength ASTM D149 V/mil 500
Surface Resistivity ASTM D257 ohm/square >10^13
COMPLIANCE
Description Value
FDA Yes - Up to 160 F Only for FDA Compliance
USDA Yes
NSF Yes
3-A Dairy No
Canadian Food Inspection Agency No
USP Class VI No
OTHER
Description Value
UV Resistant No
Relative Cost $$$$$$
Machinability 3

Relative cost based on a scale of one dollar sign ($) as the lowest to ten dollar signs ($$$$$$$$$$) as the highest. Machinability based on a scale of 1 to 10, with 1 being the easiest and 10 being the most difficult to machine. NOTE: All information contained on www.boedeker.com, downloadable documents and printed literature is intended for technical reference only and considered to be accurate for reference purposes only. Boedeker Plastics, Inc. makes no guarantee and offers no warranty for fitness in use and strongly recommends the user validate any plastic, machined part, or product in a specific application for fitness in use.

Techtron® is a registered trademark of Quadrant Engineering Plastic Products.
