VICTREX CT™ 100 Cryogenic (Kel F PCTFE Replacement in Static Sealing Applications)

Compare Go To Comparison Add Additional Products For Comparison

-

1. Select Shape

2. Please Select Thickness

2. Please Select Diameter

2. Please Select Outer Diameter

2. Please Select Type & Size

Unit of Measure

In order to provide an accurate quote for your part, you'll need to provide some information through our custom quote request form.

3. Please Select Dimensions *

Sheet widths and lengths are cut to nominal dimensions; Rod lengths are also cut to nominal dimensions. Nominal cuts can be undersized by up to .200 inches. Cut-to-size items are non-refundable. See our return policy for more details. Contact us if you need precision cut sizes.

3. Please Select Length *

Sheet widths and lengths are cut to nominal dimensions; Rod lengths are also cut to nominal dimensions. Nominal cuts can be undersized by up to .200 inches. Cut-to-size items are non-refundable. See our return policy for more details. Contact us if you need precision cut sizes.

General Info

VICTREX CT™ 100 Cryogenic Polymer is a high-performance thermoplastic material, unreinforced, semi-crystalline, available in sheet, rod, and tube,  FDA food contact compliant, natural in color. It is formulated for low-temperature performance and is ideal for PCTFE replacement in static sealing applications with resistance to erosion and chemical attack in aggressive environments.

CT 100 is a custom run product, minimums and longer lead-times will apply.

Click Here To See Our Complete Line of Cryogenic Plastics and Composites

Key Properties

  • Excellent Chemical Resistance
  • High Strength
  • Formulated for Cryogenic Static Sealing Applications
  • Higher Tensile Strength than PCTFE

Limitations

Applications

  • Static Sealing Applications
  • Pump and Valve Seals
  • Turbine Seals
  • Cryogenic (Low Temperature) Sealing Applications

Resin Trade Names

  • VICTREX CT™ 100

Manufacturer Trade Names

  • VICTREX CT™ 100

Boedeker Plastics, Inc. stocks & supplies plastic sheet, rod, tube, film and custom profiles and machine parts from these shapes that are produced from plastic resin. In many cases the manufacturer of the shape has their own product trade name. If your specification calls for a specific resin grade or manufacturer trade name, we can supply a shape made from that resin to meet your specification or suggest an equal. If you require a specific resin or brand it must be specified at the time of order.

Available Sizes

Extruded Sheet* Extruded Rod* Injection Molded Tubes* *Minimums and Longer Lead-Times may apply depending on size and quantity requested. Contact us for availability

Available Colors

  • Natural

Safety Data Sheet

Download Safety Data Sheet

Typical Properties of VICTREX CT™ 100 Cryogenic (Kel F PCTFE Replacement in Static Sealing Applications)

DETAIL
Description Value
Material Type Semi-Crystalline Thermoplastic
Chemical Name Proprietary
Trade Name VICTREX CT™ 100
Additives Unfilled
Color Natural
PHYSICAL
Property Test Unit of Measure Value
Density ISO 1183 g/cm³ 1.3
  ISO 1183 lb/in³ 0.047
MECHANICAL
Property Test Unit of Measure Value
Tensile Strength ISO 527 psi 13,778
Tensile Elongation at Break ISO 527 % 70
Flexural Strength ISO 178 psi 21,755
Flexural Modulus ISO 178 psi 507,632
Compressive Strength ISO 604 psi 17,404
Hardness ISO 868 Shore D 84 Shore D
THERMAL
Property Test Unit of Measure Value
Coefficient of Linear Thermal Expansion ISO 11359 x 10-5 in./in./°F 3.6
Max Continuous Operating Temp °C 249
  °F 480
Minimum Operating Temp °C -196
  °F -320
Thermal Conductivity ISO 22007-4 BTU-in/ft²-hr-°F 2.22
COMPLIANCE
Description Value
FDA Yes
USDA Yes
OTHER
Description Value
Relative Cost $$$$$$$
Machinability 5

Relative cost based on a scale of one dollar sign ($) as the lowest to ten dollar signs ($$$$$$$$$$) as the highest. Machinability based on a scale of 1 to 10, with 1 being the easiest and 10 being the most difficult to machine. NOTE: All information contained on www.boedeker.com, downloadable documents and printed literature is intended for technical reference only and considered to be accurate for reference purposes only. Boedeker Plastics, Inc. makes no guarantee and offers no warranty for fitness in use and strongly recommends the user validate any plastic, machined part, or product in a specific application for fitness in use.

VICTREX CT™ 100 is a trademark of Victrex plc.
