General Info
BOETEK® Static Control 21-C PC/ABS is an electrically conductive Polycarbonate/ABS alloy enhanced with carbon powder to provide uniform and reliable static control. The PC/ABS alloy combines the high impact strength, toughness, and heat resistance associated with polycarbonate with the favorable characteristics of ABS, resulting in a well-balanced engineering thermoplastic for demanding applications. BOETEK® Static Control 21-C PC/ABS uses a low carbon loading to achieve conductive performance while helping provide a slough-resistant surface. The material also offers excellent strength and toughness, low moisture absorption, and is vacuum thermoformable.
With a surface resistivity of less than 10^6 ohms, BOETEK® Static Control 21-C PC/ABS is designed for applications requiring controlled conductivity and static control. The material has a 24-hour water absorption of less than 0.2% and is supplied in sheet, rod, and tube for both machining and thermoforming applications.
Key Properties
- Conductive Static Control
- Surface Resistivity <10^6 Ohms
- High Strength
- Excellent Toughness
- Tensile Strength 62 MPa
- Tensile Modulus 2500 MPa
- Notched Izod Impact 18 kJ/m²
- Heat Deflection Temperature 112°C at 0.46 MPa
- Low Moisture Absorption <0.2%
- Low Carbon Loading
- Slough Resistant
- Vacuum Thermoformable
- Halogen Free
Limitations
- Poor Chemical Resistance to Halogens and Their Acids Including Bromine, Chlorine, Fluorine, HBr and HF
Applications
- Structural Parts for Electronics
- Semiconductor Equipment Components
- Critical Device Components
- Static Control Components
- Conductive Components
- Machined Components
- Thermoformed Components
- Vacuum Thermoformed Parts
Resin Trade Names
Manufacturer Trade Names
- BOETEK® Static Control 21-C PC/ABS
Boedeker Plastics, Inc. stocks & supplies plastic sheet, rod, tube, film and custom profiles and machine parts from these shapes that are produced from plastic resin. In many cases the manufacturer of the shape has their own product trade name. If your specification calls for a specific resin grade or manufacturer trade name, we can supply a shape made from that resin to meet your specification or suggest an equal. If you require a specific resin or brand it must be specified at the time of order.
Available Sizes
Available in Sheet, Rod and Tube. This is a made to order, call for availability.
