TIVAR ® 88 UHMW-PE w/BurnGuard (Discontinued)

Compliance Info

Slide 1 of 2, currently active
Slide 2 of 2

General Info

NOTE: THIS PRODUCT HAS BEEN DISCONTINUED

For applications in which the TIVAR® 88 liner might be exposed to combustion, TIVAR 88 with BurnGuard™ has flame retardant properties. When the source of the combustion is removed, TIVAR 88 with BurnGuard™ self extinguishes and experiences no further impact. TIVAR® 88 with BurnGuard™ meets MSHA 1C-112/1 for underground mining and has a UL94 V-0 Flammability Rating.

Due to these characteristics, TIVAR® 88 with BurnGuard™ UHMW-PE excels in applications where key components may be exposed to combustion such as bunker and chute liners, hopper liners, railcar liners, self-unloading ships, railcar liners, dragline buckets, belt scrapers, storage bin liners, vibratory feeder liners, and wear strips.

Click for more information on the complete line of TIVAR UHMW Plastics

Key Properties

Meets MSHA 1C-112/1 for underground mining
UL94 V-0 Flammability Rating
Promotes reliable, steady bulk material flow
Abrasion-, chemical- and corrosion-resistant
Low coefficient of friction
No moisture absorption
Reduces or eliminates arching, ratholing and erratic flow

Limitations

High Heat Environments
High Loads
Subject to Creep, Cold Flow
Thermal Expansion
Tight Tolerance Applications

Applications

Belt scrapers
Bunker liners
Chain conveyor flights
Chute liners
Conveyor skirting
Cyclones
Drag chain conveyor liners
Dust collection hopper liners
Hopper liners
Pugmill Paddles
Reclaimer buckets
Screw conveyor liners
Silo liners
Slider beds
Storage bin liners
Surge bin liners
Transfer chute liners
Under chain guides
Wear strips
Vibrating bin dischargers
Vibratory feeder liners

Resin Trade Names

Manufacturer Trade Names

TIVAR® 88 UHMW-PE w/BurnGuard

Boedeker Plastics, Inc. stocks & supplies plastic sheet, rod, tube, film and custom profiles and machine parts from these shapes that are produced from plastic resin. In many cases the manufacturer of the shape has their own product trade name. If your specification calls for a specific resin grade or manufacturer trade name, we can supply a shape made from that resin to meet your specification or suggest an equal. If you require a specific resin or brand it must be specified at the time of order.

Available Sizes

NOTE: THIS PRODUCT HAS BEEN DISCONTINUED

Available Colors

Black

Safety Data Sheet

Download Safety Data Sheet

Typical Properties of TIVAR ® 88 UHMW-PE w/BurnGuard (Discontinued)

DETAIL
Description			Value
Material Type			Semi-Crystalline Thermoplastic
Chemical Name			UHMW-PE Ultra High Molecular Weight Polyethylene
Trade Name			TIVAR® 88 UHMW-PE w/BurnGuard
Additives			Proprietary Additives
Color			Black
Manufacturer			MCAM
PHYSICAL
Property	Test	Unit of Measure	Value
Density	ASTM D792	g/cm³	1
	ASTM D792	lb/in³	0.036
Water Absorption, 24 hrs, Immersion	ASTM D570	% by wt.	<.01
Water Absorption, Saturation, Immersion	ASTM D570	% by wt.	<.01
MECHANICAL
Property	Test	Unit of Measure	Value
Tensile Strength	ASTM D638	psi	3,600
Tensile Modulus	ASTM D638	psi	87,000
Tensile Elongation at Break	ASTM D638	%	120
Flexural Strength	ASTM D790	psi	2,900
Flexural Modulus	ASTM D790	psi	94,000
Compressive Strength	ASTM D695	psi	2,800
Compressive Modulus	ASTM D695	psi	65,000
Hardness	ASTM D785	NA	Shore D64
IZOD Impact-Notched	ASTM D256 Type A	ft-lb/in	No Break
Dynamic Coefficient of Friction	QTM 55007 (Dry vs Steel)	NA	0.09
THERMAL
Property	Test	Unit of Measure	Value
Coefficient of Linear Thermal Expansion	ASTM D696	x 10-5 in./in./°F	9
Heat Deflection Temp	ASTM D648	°C at 264 psi	46
	ASTM D648	°F at 264 psi	116
	ASTM D3418	°C	135
	ASTM D3418	°F	275
Max Continuous Operating Temp		°C	82
		°F	180
Minimum Operating Temp		°C	-200
		°F	-328
Flammability Rating	UL94	NA	V-0
ELECTRICAL
Property	Test	Unit of Measure	Value
Surface Resistivity	ANSI/ESD STM 11.11	ohm/square	10^11
COMPLIANCE
Description			Value
FDA			No
USDA			No
NSF			No
3-A Dairy			No
Canadian Food Inspection Agency			No
USP Class VI			No
OTHER
Description			Value
UV Resistant			No
Relative Cost			$$$
Machinability			4

Relative cost based on a scale of one dollar sign ($) as the lowest to ten dollar signs ($$$$$$$$$$) as the highest. Machinability based on a scale of 1 to 10, with 1 being the easiest and 10 being the most difficult to machine. NOTE: All information contained on www.boedeker.com, downloadable documents and printed literature is intended for technical reference only and considered to be accurate for reference purposes only. Boedeker Plastics, Inc. makes no guarantee and offers no warranty for fitness in use and strongly recommends the user validate any plastic, machined part, or product in a specific application for fitness in use.

TIVAR® is a registered trademark of Mitsubishi Chemical Advanced Materials.
