PFA Perfluoroalkoxy

Compare Go To Comparison Add Additional Products For Comparison

-

1. Select Shape

2. Please Select Thickness

2. Please Select Diameter

2. Please Select Outer Diameter

2. Please Select Type & Size

Unit of Measure

In order to provide an accurate quote for your part, you'll need to provide some information through our custom quote request form.

3. Please Select Dimensions *

Sheet widths and lengths are cut to nominal dimensions; Rod lengths are also cut to nominal dimensions. Nominal cuts can be undersized by up to .200 inches. Cut-to-size items are non-refundable. See our return policy for more details. Contact us if you need precision cut sizes.

3. Please Select Length *

Sheet widths and lengths are cut to nominal dimensions; Rod lengths are also cut to nominal dimensions. Nominal cuts can be undersized by up to .200 inches. Cut-to-size items are non-refundable. See our return policy for more details. Contact us if you need precision cut sizes.

Unit Price

Subtotal

Note: There is a $50.00 line item minimum on all orders.

General Info

PerFluoroAlkoxy (PFA) offers similar properties to FEP, but is considered more of a premium resin. PFA is preferred when extended service is required in hostile environments involving chemical, thermal, and mechanical stress. PFA offers high melt strength, stability at high processing temperatures, excellent crack and stress resistance, a low coefficient of friction, and more than 10 times the Flex life of FEP. It has high resistance to creep and retention of properties after service at 500°F (260°C), with useful properties at -320°F (95°C). PFA also meets FDA 21CFR.177.1550.

Click for more information on the complete line of Fluoropolymers

Key Properties

  • Crack Resistant
  • Creep Resistant
  • Excellent Flex Life
  • Low Coefficient of Friction
  • Outstanding Chemical Resistance
  • Wide Operating Temp Range of -320F to 500F

Limitations

Applications

  • <ul><li><span>Aircraft Wire, Plenum Cable, Fire Alarm Cable, And Well Logging Cable</span></li><li><span>Chemical Processing Components
  • </span><span>Linings for Pipe And Chemical Processing Equipment</span></li><li><span>Pump &amp; Valve Components</span></li><li><span>Roll Covers</span></li><li><span>Wire and Cable Applications</span></li><li><span>Seals</span></li></ul><p><span>&nbsp;</span></p>

Resin Trade Names

Manufacturer Trade Names

Boedeker Plastics, Inc. stocks & supplies plastic sheet, rod, tube, film and custom profiles and machine parts from these shapes that are produced from plastic resin. In many cases the manufacturer of the shape has their own product trade name. If your specification calls for a specific resin grade or manufacturer trade name, we can supply a shape made from that resin to meet your specification or suggest an equal. If you require a specific resin or brand it must be specified at the time of order.

Available Sizes

Available Colors

  • Natural

Safety Data Sheet

Download Safety Data Sheet

Typical Properties of PFA Perfluoroalkoxy

DETAIL
Description Value
Material Type Semi-Crystalline Thermoplastic Fluoropolymer
Chemical Name PFA Perfluoroalkoxy
Additives Unfilled
Color Natural
PHYSICAL
Property Test Unit of Measure Value
Density ASTM D792 g/cm³ 2.15
  ASTM D792 lb/in³ 0.078
Water Absorption, 24 hrs, Immersion ASTM D570 % by wt. <.03
MECHANICAL
Property Test Unit of Measure Value
Tensile Strength ASTM D638 psi 3,600
Tensile Elongation at Break ASTM D638 % 300
Flexural Modulus ASTM D790 psi 85,000
IZOD Impact-Notched ASTM D256 ft-lb/in No break
Dynamic Coefficient of Friction ASTM D1874 0.2
THERMAL
Property Test Unit of Measure Value
Coefficient of Linear Thermal Expansion ASTM D696 x 10-5 in./in./°F 6.7
Max Continuous Operating Temp °C 260
  °F 500
Minimum Operating Temp °C -195
  °F -320
Flammability Rating UL94 NA V-0
ELECTRICAL
Property Test Unit of Measure Value
Dielectric Constant at 1 MHz ASTM D150 NA 2.1
COMPLIANCE
Description Value
FDA Yes
USDA Yes
NSF No
3-A Dairy No
Canadian Food Inspection Agency No
USP Class VI No
OTHER
Description Value
UV Resistant Yes
Relative Cost $$$$$$
Machinability 3

Relative cost based on a scale of one dollar sign ($) as the lowest to ten dollar signs ($$$$$$$$$$) as the highest. Machinability based on a scale of 1 to 10, with 1 being the easiest and 10 being the most difficult to machine. NOTE: All information contained on www.boedeker.com, downloadable documents and printed literature is intended for technical reference only and considered to be accurate for reference purposes only. Boedeker Plastics, Inc. makes no guarantee and offers no warranty for fitness in use and strongly recommends the user validate any plastic, machined part, or product in a specific application for fitness in use.
