General Info

KETRON ® PEEK LSG stock shapes are produced from selected batches of Victrex ® PEEK PolyEtherEtherKetone resin. This material exhibits a unique combination of mechanical properties, temperature and chemical resistance. The composition of the resin used for production of the KETRON ® PEEK-LSG stock shapes complies with the regulations that apply in the Member States of the European Union (Directive 2002/72/EC, as amended) and in the United States of America (FDA) for plastic materials and articles intended to come into contact with foodstuffs.

Click for more information on the complete line of Ketron PEEK Plastic Products

Key Properties

Limitations

Applications

Resin Trade Names

Manufacturer Trade Names

Ketron® PEEK LSG

Boedeker Plastics, Inc. stocks & supplies plastic sheet, rod, tube, film and custom profiles and machine parts from these shapes that are produced from plastic resin. In many cases the manufacturer of the shape has their own product trade name. If your specification calls for a specific resin grade or manufacturer trade name, we can supply a shape made from that resin to meet your specification or suggest an equal. If you require a specific resin or brand it must be specified at the time of order.

Available Sizes

Available Colors

Safety Data Sheet

Download Safety Data Sheet

Typical Properties of Ketron ® PEEK LSG

DETAIL
Description			Value
Material Type			Semi-Crystalline Thermoplastic
Chemical Name			PEEK Polyetheretherketone
Trade Name			Ketron® PEEK LSG
Additives			Unfilled
Color			Tan & Black
Manufacturer			Quadrant
PHYSICAL
Property	Test	Unit of Measure	Value
Density	ISO 1183	g/cm³	1.31
	ISO 1183	lb/in³	0.047
Water Absorption, 24 hrs, Immersion	ISO 62	% by wt.	0.06
MECHANICAL
Property	Test	Unit of Measure	Value
Tensile Elongation at Break	ISO 527	%	17
Hardness	ISO 2039-2	NA	Rockwell M105
THERMAL
Property	Test	Unit of Measure	Value
Max Continuous Operating Temp		°C	249
		°F	480
Minimum Operating Temp		°C	-60
		°F	-76
Thermal Conductivity	ASTM C117	BTU-in/ft²-hr-°F	1.7
Flammability Rating	UL94	NA	V-0
COMPLIANCE
Description			Value
FDA			Yes
USDA			Yes
NSF			No
3-A Dairy			No
Canadian Food Inspection Agency			No
USP Class VI			Yes
OTHER
Description			Value
UV Resistant			No
Relative Cost			$$$$$$$$
Machinability			5

Relative cost based on a scale of one dollar sign ($) as the lowest to ten dollar signs ($$$$$$$$$$) as the highest. Machinability based on a scale of 1 to 10, with 1 being the easiest and 10 being the most difficult to machine. NOTE: All information contained on www.boedeker.com, downloadable documents and printed literature is intended for technical reference only and considered to be accurate for reference purposes only. Boedeker Plastics, Inc. makes no guarantee and offers no warranty for fitness in use and strongly recommends the user validate any plastic, machined part, or product in a specific application for fitness in use.

Ketron® is a registered trademark of Quadrant Engineering Plastic Products.
