TECASON ® P MT XRO PPSU Radel ® R

Compliance Info
TECASON ® P MT XRO PPSU Radel ® R
Previous Next
  • Slide 1 of 5, currently active
  • Slide 2 of 5
  • Slide 3 of 5
  • Slide 4 of 5
  • Slide 5 of 5
Previous Next

Compare Go To Comparison Add Additional Products For Comparison

-

1. Select Shape

2. Please Select Thickness

2. Please Select Diameter

2. Please Select Outer Diameter

2. Please Select Type & Size

Unit of Measure

In order to provide an accurate quote for your part, you'll need to provide some information through our custom quote request form.

3. Please Select Dimensions *

Sheet widths and lengths are cut to nominal dimensions; Rod lengths are also cut to nominal dimensions. Nominal cuts can be undersized by up to .200 inches. Cut-to-size items are non-refundable. See our return policy for more details. Contact us if you need precision cut sizes.

3. Please Select Length *

Sheet widths and lengths are cut to nominal dimensions; Rod lengths are also cut to nominal dimensions. Nominal cuts can be undersized by up to .200 inches. Cut-to-size items are non-refundable. See our return policy for more details. Contact us if you need precision cut sizes.

General Info

TECASON®P XRO PPSU has a radio opacifer additive formulated for orthopedic sizing trials and other instrument devices allowing for clear visibility of the component on fluoroscopy and xray. TECASON™P XRO has been tested to the requirements of IS0 10993 for external communication devices intended for less than 24 hour contact with tissue, bone and dentin.

Click for more information on the complete line of Radel PPSU Plastics

Key Properties

  • Tested to The Requirements of ISO 10993
  • High Tensile Strength
  • Excellent Heat Resistance, Autoclavable
  • Very High Resistance to Environmental Stress
  • Great Mechanical Strength
  • High Dielectric Strength and Stability
  • X-Ray Opaque

Limitations

  • Attacked by Some Solvents
  • Poor Weatherability
  • Subject to Stress Cracking

Applications

  • Othopedic Trials

Resin Trade Names

  • Radel®

Manufacturer Trade Names

  • TECASON® P MT XRO

Boedeker Plastics, Inc. stocks & supplies plastic sheet, rod, tube, film and custom profiles and machine parts from these shapes that are produced from plastic resin. In many cases the manufacturer of the shape has their own product trade name. If your specification calls for a specific resin grade or manufacturer trade name, we can supply a shape made from that resin to meet your specification or suggest an equal. If you require a specific resin or brand it must be specified at the time of order.

Available Sizes

Available Colors

  • Colors

Safety Data Sheet

Download Safety Data Sheet

Typical Properties of TECASON ® P MT XRO PPSU Radel ® R

DETAIL
Description Value
Material Type Amorphous Thermoplastic
Chemical Name PPSU Polyphenylsulfone
Trade Name TECASON® P MT XRO
Additives Radio-opaque
Color Medical Grade Colors
Manufacturer Ensinger
PHYSICAL
Property Test Unit of Measure Value
Density ASTM D792 g/cm³ 1.36
  ASTM D792 lb/in³ 0.049
Water Absorption, 24 hrs, Immersion ASTM D570 % by wt. 0.19
MECHANICAL
Property Test Unit of Measure Value
Tensile Strength ASTM D638 psi 11,500
Tensile Modulus ASTM D638 psi 420,000
Tensile Elongation at Break ASTM D638 % 35
Flexural Strength ASTM D790 psi 18,000
Flexural Modulus ASTM D790 psi 350,000
Compressive Strength ASTM D695 psi 13,700
Compressive Modulus ASTM D695 psi 225,000
Hardness ASTM D785 NA Rockwell M92
IZOD Impact-Notched ASTM D256 ft-lb/in 1.6
THERMAL
Property Test Unit of Measure Value
Max Continuous Operating Temp °C 149
  °F 300
Minimum Operating Temp °C -50
  °F -58
COMPLIANCE
Description Value
FDA Yes
USDA No
NSF No
3-A Dairy No
Canadian Food Inspection Agency No
USP Class VI Yes
OTHER
Description Value
UV Resistant No
Relative Cost $$$$$$
Machinability 3

Relative cost based on a scale of one dollar sign ($) as the lowest to ten dollar signs ($$$$$$$$$$) as the highest. Machinability based on a scale of 1 to 10, with 1 being the easiest and 10 being the most difficult to machine. NOTE: All information contained on www.boedeker.com, downloadable documents and printed literature is intended for technical reference only and considered to be accurate for reference purposes only. Boedeker Plastics, Inc. makes no guarantee and offers no warranty for fitness in use and strongly recommends the user validate any plastic, machined part, or product in a specific application for fitness in use.

TECASON® is a registered trademark of Ensinger. Radel® is a registered trademark of Solvay.
