General Info

XtremeEPP™ 1892 CFB Composite Frac Balls offer are formulated for applications that require a ball that with a custom specific gravity of 1.8, high strength, tough and dimensionally stable.

XtremeEPP™ 1892 CFB Composite Frac Balls have mechanical properties that are not affected by fiber reinforcement orientation like G-10 and other common composites used for frac balls.  This offers the benefit of consistent mechanical properties regardless of ball orientation when it is seated in the plug.

Key Features include a Specific Gravity of 1.8, 350 F Service Temp., Uniaxial Compression Strength of 17,835 PSI and a Hydrostatic Crush of over 22,000 PSI.

Custom specific gravity formulations are available.

Key Properties

  • High Service Temp of 350 F
  • 1.8 Specific Gravity
  • High Strength
  • Mechanical properties are not affected by fiber orientation like G-10 and other common composites used for frac balls offering consistent properties regardless of ball orientation
  • Hydrostatic Crush >22,000 PSI
  • Uniaxial Compressive Strength Max 17,835 PSI

Limitations

Applications

  • Frac Balls
  • Hydraulic Fracturing Applications

Resin Trade Names

Manufacturer Trade Names

  • XtremeEPP ™ 1892 CFB Composite Frac Balls

Boedeker Plastics, Inc. stocks & supplies plastic sheet, rod, tube, film and custom profiles and machine parts from these shapes that are produced from plastic resin. In many cases the manufacturer of the shape has their own product trade name. If your specification calls for a specific resin grade or manufacturer trade name, we can supply a shape made from that resin to meet your specification or suggest an equal. If you require a specific resin or brand it must be specified at the time of order.

Available Sizes

XtremeEPP Frac Balls are precision manufactured in .125-inch increments in diameters from 1.000 to 4.500 inches. Custom sizes are available.

Available Colors

  • Ivory Gray

Safety Data Sheet

Contact Us

Typical Properties of XtremeEPP ™ 1892 CFB Composite Frac Balls 1.8 SG

DETAIL
Description Value
Material Type Thermoset Composite
Trade Name XtremeEPP ™ 1892 CFB Composite Frac Ball 1.8 SG
Additives Proprietary
Color Ivory Gray
PHYSICAL
Property Test Unit of Measure Value
Density ASTM D2240 g/cm³ 1.8
  ASTM D2240 lb/in³ 0.065
MECHANICAL
Property Test Unit of Measure Value
Compressive Strength ASTM D695 uniaxial psi max 17,835
Compressive Modulus ASTM D695 uniaxial psi 1,550,000
Hardness ASTM D2240 Shore D 90 Shore D
THERMAL
Property Test Unit of Measure Value
Max Continuous Operating Temp °C 176
  °F 350

NOTE: All information contained on www.boedeker.com, downloadable documents and printed literature is intended for technical reference only and considered to be accurate for reference purposes only. Boedeker Plastics, Inc. makes no guarantee and offers no warranty for fitness in use and strongly recommends the user validate any plastic, machined part, or product in a specific application for fitness in use.

XtremeEPP™ is a registered trademark of Boedeker Plastics, Inc.
